Details
|
|
The Byrd® helical cutterhead with 74 four-sided knife inserts provides smoother, quieter cutting and finer finish than conventional systems
|
|
Powerful 3HP TEFC motor controlled with a magnetic switch for safety
|
|
Three V-belts transfer maximum power to the cutterhead
|
|
Serrated steel infeed roller and smooth steel outfeed roller allow for 1/8" maximum depth of cut and trouble free operation
|
|
Large cast iron handwheel positions table quickly and easily
|
|
Large, precision ground cast iron table and extensions provide maximum workpiece support
|
|
Two speed gearbox features automatic chain tensioner
|
|
One-piece welded steel stand has built-in lockable casters
|
|
Steel top-mounted return rollers speed repetitive cuts
|
|
Angled dust chute with 4" port positions collection hose away from the work area while providing efficient chip and dust collection
|
|
Table locks firmly in place, preventing movement during cutting
|
|
Standard Equipment:
|
|
3HP TEFC motor with magnetic controls
|
|
Byrd® helical cutterhead with inserts
|
|
4" diameter dust port
|
|
Cast iron extension tables
|
|
Closed stand with built-in casters
|
