ArmorGlide 12-Inch Parallelogram Jointer, Straight Knife, 230V 1Ph (1285T)

Stock Number: PM1-1791241T

0 Reviews

No reviews yet.

  • Low-friction coating provides more control
  • Cutterhead with three high-speed steel knives
  • 12" x 84" precision-ground cast iron table
  • Rack and pinion adjustable fence
$7,999.00
WAS$9,569.00

Financing Starting at $187 per month -

Item Quantity: 1
Contact a Specialist - 855-657-4653

Product Details

The Powermatic 1285T ArmorGlide 12-inch parallelogram jointer with a straight-knife cutterhead and 230V single-phase power provides traditional cutting performance with modern table protection. ArmorGlide Technology creates a low-friction, rust-resistant surface that improves stock movement and extends table life. Driven by a 3 HP motor, the straight-knife cutterhead delivers reliable jointing performance for a wide range of materials. The parallelogram table design allows quick depth-of-cut changes while maintaining consistent alignment for accurate results. A center-mounted fence with rack-and-pinion adjustment offers smooth positioning and includes preset stops for 45-degree angles and a positive 90-degree stop. Heavy cast iron construction throughout the machine enhances stability and vibration control, making this jointer a dependable choice for professional shops that prefer straight-knife systems.

Features

  • ArmorGlide-coated cast iron tables reduce friction and resist rust, allowing smoother stock travel and less surface maintenance over time
  • Three-knife straight cutterhead uses high-speed steel knives to deliver traditional jointing results with consistent edge engagement
  • 3 HP single-phase motor provides steady power for jointing wide boards and dense stock without requiring three-phase service
  • Parallelogram table design keeps tables closely aligned to the cutterhead while allowing fast, accurate depth-of-cut adjustments
  • Large 12-inch by 84-inch precision-ground cast iron table supports long material for improved accuracy and stability
  • Center-mounted cast iron fence adjusts via rack-and-pinion control for smooth movement and repeatable positioning
  • Fence preset stops enable quick setup at common angles, including 45 degrees and a positive stop at 90 degrees
  • Heavy cast iron construction reduces vibration during operation for smoother cuts and consistent jointing results
  • Cast iron table lips near the cutterhead help dampen operational noise during cutting passes
  • Designed for controlled cutting depths up to 1/8 inch for jointing and up to 1/2 inch for rabbeting

Specifications

  • SKU
    PM1-1791241T
  • Coating
    ArmorGlide Technology
  • Cutterhead Speed (RPM)
    5000
  • Cutting Capacity Width
    11.75 in.
  • Dust Port Outside Diameter (in.)
    4 in.
  • Fence Size
    47-1/4 x 5-1/4 in.
  • Gross Weight
    880
  • Input Power
    230V Single Phase
  • Model Number
    1285T
  • Motor HP
    3
  • Net weight
    762
  • Number of Knives
    3
  • Old Material Number
    1791241T
  • Prewired Voltage
    230
  • Product Type
    Machines
  • Prop 65
    Cancer and Reproductive Harm
  • Table Height
    31-5/8
  • Type of Cutterhead
    Straight Knife
  • Warranty
    5 Year
